Thermogravimetric analysis (TG, TGA) is to observe the change of sample mass with temperature or time during heating, constant temperature or cooling process, in order to study the thermal stability and composition of materials. It is widely used in research and development, process optimization and quality control of plastics, rubber, coatings, pharmaceuticals, catalysts, inorganic materials, metal materials and composite materials.
Brand：Jiuban
Model：TGA-1200
Name：Thermogravimetric analyzer
一、Product Overview：
Thermogravimetric analysis (TG, TGA) is to observe the change of sample mass with temperature or time during heating, constant temperature or cooling process, in order to study the thermal stability and composition of materials. It is widely used in research and development, process optimization and quality control of plastics, rubber, coatings, pharmaceuticals, catalysts, inorganic materials, metal materials and composite materials.
The following characteristics of materials were measured and studied: thermal stability, decomposition process, adsorption and desorption, oxidation and reduction, quantitative analysis of components, effects of additives and fillers, moisture and volatiles, reaction kinetics.
二、Technical parameters:
1. Temperature Range：RT~1200℃
2. Temperature Resolution: 0.1℃
3. Temperature Fluctuation: +0.1℃
4. Heating rate: 1-80℃/min
5. Temperature control methods: heating, constant temperature, cooling
6. Cooling time: 15 min (1000℃…100℃)
7. The measuring range of balance is：1 mg~2 g, which can be extended to 30 G.
8. Sensitivity：0.01mg
9. Constant temperature time：0-300 min utes arbitrarily set
10. Display mode：large LCD display of Chinese characters
11. Atmosphere device：built-in gas flowmeter, including two-way gas switching and flow size control (atmosphere: inertia, oxidation, reduction, static, dynamic)
12. Software：Intelligent software can automatically record TG curve for data processing and printing experimental report forms.
13. Data Interface：Standard USB Interface, Special Software (Software Upgraded Freely from Period)
14. Power supply：AC220V 50Hz
15. Appearance size：489*400*343 mm (length, width and height)
